Specification:
Brand: XIAOMI
Model: 9290029051
Main Material: ABS plastic
Color: White
Scene: Indoor Use
Working Temperature: -10 ℃~ +25 ℃
Light Source: LED Chip
Color Temperature: 4000K
CRI: 90
Luminous Flux: 600lm
Button Dimming: 3 Level Brightness
APP Smart Dimming : Stepless Dimming
Rated Voltage: 220~240V
Rated Frequency: 50 / 60Hz
Rated Current: 0.08A
Rated Power: 7.6W (42 × 0.16W / LED module)
Power Factor: 0.4
Product Size: 408 *140 *410mm
Net Weight: 0.5 kg

Plug: CN Plug

Features:
- Smart Connectivity: Easily connects to the MiHome APP via Bluetooth Mesh for convenient control and voice command compatibility with Xiao Ai speaker.

Note: This lamp is Chinese Version, please set the server of APP to China Mainland.
- Fixed Color Temperature: Features a fixed 4000K color temperature, providing consistent and comfortable lighting for reading and working.
- Adjustable Brightness: Offers three brightness levels, allowing users to customize lighting according to their needs and preferences.
- Stylish and Compact Design: With dimensions of 408x140x410mm and a lightweight design, it fits seamlessly into any workspace or home environment.
- Safe and Quality Construction: Made from high-quality ABS material and equipped with a reliable power source, ensuring durability and safety during use.

Instructions for Use:

◆ How to operate the power button on the Xiaomi Mijia Smart Desk Lamp Lite?
Short press: Turn on/off the lamp.

Long press: Cycle through three brightness levels, stopping at the current brightness when released.
◆ How to reset the Xiaomi Mijia Smart Desk Lamp Lite?
While the lamp is plugged in & light off, long press the power button for 7 seconds until the light turns on and flashes, indicating a successful reset.

◆How to connect the Xiaomi Mijia Smart Desk Lamp Lite to the MiHome APP?
The lamp can be connected to the MiHome APP through one of the following methods:

  1. Manual Device Addition via MiHome APP (Recommended: Prepare a Bluetooth Mesh gateway in advance)
  Connect a smart device with Bluetooth Mesh gateway capabilities to the network.
  Reset the lamp to factory settings.
  Keep the phone's Bluetooth on and close to the lamp.
  Open the MiHome APP, tap the '+' in the upper right corner to add the device.
  When the lamp shows 'Connected to Bluetooth Mesh gateway,' the connection is successful.

  2. Voice Addition via Bluetooth Mesh Gateway
  Connect a smart voice device with Bluetooth Mesh capabilities and built-in 'Xiao Ai' to the network, and reset the lamp.
  Speak 'Xiao Ai' to the smart voice device.
  Follow voice prompts to complete the lamp addition.

  3. Direct Bluetooth Connection (No Mesh Gateway Required)
  Keep the phone's Bluetooth on and close to the lamp.
  Reset the lamp to factory settings.
  Open the MiHome APP, tap the '+' in the upper right corner.
  When the lamp shows 'Connected to phone,' the connection is successful.

◆ What to do if the Xiaomi Mijia Smart Desk Lamp Lite shows offline in the MiHome APP?
Please check if there is no Bluetooth Mesh gateway device at home, as this lamp requires a Bluetooth Mesh gateway for use. If not connected, reset the lamp and follow the instructions in 'How to connect the Xiaomi Mijia Smart Desk Lamp Lite to the MiHome APP' using Method 1 for adding and configuring. Once configured, it will show online. (However, if the phone used for configuration turns off Bluetooth or moves away from the lamp, the lamp will go offline again.) If connected to a Bluetooth Mesh gateway: check if the lamp is powered, ensure that the device with Bluetooth Mesh capability is online, and verify that the gateway device's Bluetooth Mesh function is enabled.
Note: When direct connection, night light mode, timed switching, light group, and voice control functions are not supported.

It is recommended to prepare a Bluetooth Mesh gateway for use at home. The Xiaomi Mijia Smart Desk Lamp Lite only supports connection via a Bluetooth Mesh gateway and does not support Bluetooth gateway connections. The interface title 'Connected to Bluetooth Mesh gateway' indicates a successful gateway connection.

Package Included:
1 x Desk Lamp
