Description:
Automatic selection of measuring function and range.
Full range overload protection.
Automatic shutdown timer: 15 minutes
Sampling time: about 3 times/second
Model |
SZ02 |
SZ01 |
AC Current |
999.9mA/10A |
600.0mA/10A |
DC Current |
999.9mA/10A |
600.0mA/10A |
DC Voltage |
600.0mV/9.999V/99.99V/999.9V |
600.0mV/6.000V/60.00V/600.0V |
AC Voltage |
600.0mV/9.999V/99.99V/999.9V |
600.0mV/6.000V/60.00V/600.0V |
Line on-off Test |
1Ω |
1Ω |
Resistance |
999.9Ω/9.999kΩ/99.99kΩ/ |
600.0Ω/6.000kΩ/60.00kΩ/ |
Diode Test |
1V |
1V |
Capacitor |
9.999nF999.9nF/9.999uF/ |
|
NCV |
YES |
YES |
Temperature |
-40~1000℃ |
NO |
-40~1832℉ |
NO |
|
Frequency |
100Hz/1000Hz |
100Hz/1000Hz |
Backlight |
yes |
yes |
Packing includes:
1 x SZ02 Multimeter
2 x Test Leads
1 x Temperature probe
1 x User Manual
1 x Packing Box
>>Please click here to download the English manual<<
