Specifications:
Model: UT698-15KIT / UT698-30KIT
Detector Type: InGaAs
Wavelength Response Range: 700-1700nm
Power Meter Port: 2.5mm universal port
Calibration Wavelengths: 850nm, 980nm, 1270nm, 1300nm, 1310nm, 1490nm, 1550nm, 1577nm, 1625nm, 1650nm
Measurement Range: -50~+30dBm
Accuracy: ±0.4dB (1310nm, 1490nm, 1550nm, 1625nm) / ±1dB (850nm, 1300nm, 980nm, 1270nm, 1650nm)
Resolution: 0.01dBm
Display Units: dBm, dB, W (mW/μW automatic switching)
Frequency Identification: 270Hz, 330Hz, 1kHz, 2kHz
Data Storage Capacity: 500 groups
Power Output: 15mW for UT698-15KIT / 30mW for UT698-30KIT
Laser Output Mode: CW/2 ± 1Hz flash
Cable Test Range: Up to 600 meters
Cable Test Ports: RJ45 (8P8C+G)
Detection Mode: Analog & digital
LED Indicator: White light illumination
Battery: 3.7V 450mAh lithium battery with USB Type-C charging
Main Unit Dimensions: 114 x 65 x 29mm
Main Unit Weight: Approx. 110g
Receiver Dimensions: 180 x 45 x 26mm
Receiver Weight: Approx. 105g
Operating Temperature: -10°C to +50°C
Storage Temperature: -20°C to +45°C


Features:
1.Wide Compatibility: Equipped with a 2.5mm universal optical port, the device supports multiple wavelengths and adapts to various types of optical fibers.
2.Accurate Optical Measurements: High precision with ±0.4dB calibration accuracy for specific wavelengths and cutting-edge detection range up to -50 to +30dBm ensures reliable measurement results.
3.Comprehensive Cable Testing: Offers fast tracing of Ethernet cables up to 600 meters, enabling efficient network installation and maintenance across multiple environments.
4.Enhanced Functionality: With NCV non-contact voltage detection capabilities, users can safely identify power lines without direct physical contact.
5.Portable Design: Compact lightweight structure, paired with a rechargeable lithium battery, ensures ease of use and long-lasting performance for field professionals.


Package Included:
1 x Main Unit
1 x Receiver
1 x RJ45 Jumper Cable
1 x RJ45 Crocodile Test Cable
1 x Type-C Charging Cable
1 x Set of Earphones
1 x Storage Bag
1 x Instruction Manual
