Feature:
>>>Manual: Click here to open<<<
Driver chip SSD1309
Support interface IIC/SPI
Resolution 128×64
Display size 2.42 inches
Display color: white/blue/yellow/green (optional)
Module size 71×43.5 (mm)
Glass size 60.5×37.00× (mm)
Display area 55.02×27.49 (mm)
Drive voltage 3.3-5V
Number of pins 7PIN
Viewing angle >160°
Working temperature -40℃~70℃
Storage temperature -40℃~80℃
SPI Interface Definition:
1. GND - Power Ground
2. VDD - Power Supply Positive (2.8-5.5V)
3. SCK - Clock Line
4. SDA - Data Line
5. RES - Reset Line
6. DC - Data/Command
7. CS - Chip Select
Package includes:
1 x OLED screen
