Specifications:

Material:

Plastic components

M2.5 steel screws (Zinc plated)

Contact materials: phosphor bronze (Ni plated) or stainless steel

Pin header: Copper (Tin plated)

Housing: PBT, UL94V-0

Electrical:

Rated voltage: 300V

Rated current: 15A

Contact resistance: 20mΩ

Insulation resistance: 5000MΩ/1000V

Withstanding Voltage: AC1500V/1Min

Wire range: 22-14AWG/2.5mm²

Mechanical:

Temperature range: -30°C to +120°C

Maximum soldering temperature: +250°C for 5 seconds

Torque: 0.5Nm (3.6lb.in)

Strip length: 4.5-5mm

Features:

1. High Electrical Performance: Designed to handle a rated voltage of 300V and current up to 15A, this connector ensures robust and stable electrical performance for various applications, from industrial equipment to consumer electronics.

2. Superior Contact Materials: The use of phosphor bronze with nickel plating or stainless steel for contacts ensures excellent conductivity and resistance to corrosion. This enhances the longevity and reliability of the connections, providing peace of mind in critical applications.

3. Versatile Housing and Header Materials: The housing is made from PBT material, compliant with UL94V-0 safety standards, which
