Specifications:

- Operating Frequency: 300-330MHz

- Maximum Output Power (P1dB): 8W (39dBm) @8V 1.56A Efficiency 65%

- Input Power: 20~23dBm (0.1~0.2W), works below 0.1W with increased output as input power increases

- Operating Voltage: 6-8.4V (typical lithium battery supply voltage)

- Operating Current: 1.6A (Max)

- Input Impedance: 50 Ohms

- Output Impedance: 50 Ohms

- Connectors: SMA-k female (external thread, inner hole)

- Dimensions: 4x5.5cm (excluding protruding parts)

- Weight: 58g

- Performance: 8V supply, output 39.2dBm (8.3W), efficiency 66.6%

Features:

1. High Output Power:

   Delivers up to 8W (39dBm) output, ensuring strong and reliable signal transmission within the 300-330MHz frequency range.

2. Energy Efficient:

   Achieves an impressive efficiency of up to 66.6% at 8V supply, optimizing power consumption for longer battery life.

3. Compact and Lightweight:

   With dimensions of 4x5.5cm and weighing only 58g, this module is ideal for space-constrained applications without adding significant weight.

4. SMA-k Connectors:

   Equipped with standard SMA-k female connectors, allowing for easy integration with existing UHF communications setups.

5. Stable Performance:

   Requires a properly matched 50 Oh
