Specifications:

>>>Manual: Click here to open<<<

- Display: 3.2-inch color resistive touch screen

- Frequency Range:

  - Display Frequency Range: 35 — 6200 MHz

  - Measurement Frequency Range: 35 — 6200 MHz

- Dynamic Range:

  - 35-3000 MHz: 75 dB

  - 3000-4500 MHz: 70 dB

- Maximum Span: 6165 MHz

- Bandwidth: 200 kHz (fixed)

- Scan Speed for Frequency Bands over 100 MHz: 700 MHz/sec

- 100 MHz Scan Time: <0.25 sec

- Noise Floor:

  - Up to 3000 MHz: <-90 dBm

  - 3000-4500 MHz: <-85 dBm

  - 4500-6200 MHz: <-80 dBm

- Wave Impedance: 50 ohms

- SWR (Standing Wave Ratio): <1.5 within operational frequency range

- Internal Attenuator Range: 0-30 dB

- Attenuation Accuracy:

  - Up to 10 dB: 2 dB

  - 10 to 20 dB: 5 dB

  - 20 to 30 dB: 8 dB

- Tracking Generator Output Power: -15 to -25 dBm

- Accuracy within Dynamic Range: 2.0 dB<
