Specifications:

Rated parameters:
Rated voltage: 12V~24V/DC (11V/MIN~30V/MAX, limit voltage
No-load current: <500mA (current limit: 10A, it is recommended to use a switching power supply or battery greater than 15A)
Limit angle: ±180° or 0°~360° (MAX) The servo has electronic limit adjustment
RC mode: 1ms Pulse mode: 1ms~2ms (pulse width)/50Hz (cranial rate) suitable for wireless remote control control
2ms pulse mode: 0.5ms~2.5ms (pulse width)/50Hz (frequency) suitable for multi-channel steering gear controller control
Analog voltage mode: 0V-3.3V input voltage (OV corresponds to 0, 3.3V corresponds to 360°)
Control resolution: 360° corresponding to 15Bit resolution (32768), ARM32-bit MCU, real digital port to read magnetically encoded data
Material: Gear and shaft: alloy steel; Gear box: cast aluminum
Weight: 550g
Overall dimensions: 95mm*60mm*110mm
Mechanical life: >1,000,000 times/full load (conservative value)

Limit parameters:
Limit voltage: 11V-30V/DC (MAX)
Current limit value: 10A±0.2A(MAX)
Working angle: 180° or 0°~360°(MAX)

RC mode:
1ms pulse mode: 1ms~2ms (pulse width) 50Hz~333Hz (frequency)
2ms pulse mode: 0.5ms~2.5ms (pulse width)/50Hz~333Hz (frequency)
Analog voltage mode: 0V-3.3V input voltage 0V corresponds to 0°, 3.3V corresponds to 360°
Weight: 510g~560g

Features:

Suitable for ostrich aircraft controller, model aircraft wireless remote control and analog voltage control
Alloy gear high power motor high torque output
Aluminum alloy reduction box is ultra-light weight
Easy to install, sturdy and durable


Application Scope:
Heavy-load motion control of arm joints and leg joints of large robots
Industrial automation production line robot control
Precise control of door cutting angle
Large camera pan/tilt remote control
Various occasions requiring large torque angle control

Package Include:
1x ASMG-MTB Module Board
