Rated power: 1000W
AC voltage: 230VAC
Frequency: 50Hz
Resistive load continuous output power: 800W
Capacitive load continuous output power: 280±20W, PF value: 0.51 (tri-color energy-saving lamps, exceeding may protect, but will not cause damage to the inverter)
Waveform: pure sine wave
Battery voltage: 12Vdc
Voltage range: 9.5V～15.5Vdc
DC current: 85.2A (900W resistive load, input 12Vdc)
No-load loss: ≤1A (input 12Vdc)
Shutdown mode quiescent current: ≤1mA
Fan work: temperature and power control mode
Maximum efficiency: 91%
Battery input protection:
Fuse: 40A*3
Low battery alarm: 10Vdc buzzer alarm: Beep @ 0.5 Hz, LCD display code 06
Low battery alarm recovery: 11Vdc
Battery low voltage protection: 9.5Vdc to turn off inverter output, buzzer alarm: Beep @ 1 Hz, LCD screen displays code 01, 30S does not recover and automatically shuts down
Battery low voltage protection recovery: 12Vdc
Battery high voltage protection: 15.5Vdc turns off the inverter output, buzzer alarm: Beep @ 1 Hz, LCD screen displays code 02, 30S does not recover and automatically shuts down
Battery high voltage protection recovery: 15Vdc
Output protection:
High temperature protection: turn off inverter output, buzzer alarm: Beep @ 0.5 Hz, LCD display code 04
High temperature protection recovery: The inverter output is automatically restored when the temperature drops
Output short circuit: With short circuit protection, the inverter output will be turned off when the output is short circuited, the buzzer will alarm: Beep @ 1 Hz, the LCD screen will display the code 03, it will automatically shut down after 30 seconds, remove the short circuit and restart the machine to restore the output
Overload: 1. ENHANCE mode: when the load exceeds 1000±100W, enter constant current mode, continue to increase the power until the output voltage is lower than 160Vac, then turn off the inverter output in 10S, automatically shut down in 30S, turn off the load and restart to resume output
2. Normal mode: the load exceeds 1000±100W and enters the constant current mode, continue to increase the power until the output voltage is lower than 175Vac, then turn off the inverter output in 10S, automatically shut down in 30S, turn off the load and restart to resume output
Buzzer alarm: Beep @ 1 Hz, LCD display code 05
Output voltage: 5Vdc
Output current: 2.1A
Working temperature: 0～40℃
Working humidity: 10～90%RH
Storage temperature and humidity -20℃～60℃, 10～95%RH
Net weight: 1.9Kg
Size: 280*158*90mm(L*W*H)
Features:
1. Pure sine wave
2. Peak power up to 2000W
3. Various types of protection: input high/low voltage protection, output short circuit protection, overload protection,
4. Applications: home appliances, power tools, office and portable equipment, vehicles and yachts, etc.
2. Peak power up to 2000W
3. Various types of protection: input high/low voltage protection, output short circuit protection, overload protection,
4. Applications: home appliances, power tools, office and portable equipment, vehicles and yachts, etc.
-- 5000W Specifications:
Rated power: 1500W
AC voltage: 230Vac
Frequency: 50Hz
Resistive load continuous output power: 1500W
Capacitive load continuous output power: 490±50W, PF value: 0.584 (tri-color energy-saving lamps, exceeding may protect, but will not cause damage to the inverter)
Waveform: pure sine wave
Battery voltage: 12Vdc
Voltage range: 9.5V～15.5Vdc
DC current: 132.6A (1400W resistive load, input 12Vdc)
No-load loss: ≤1.4A (input 12Vdc)
Shutdown mode quiescent current: ≤1mA
Fan work: temperature and power control mode
Maximum efficiency: 91%
AC voltage: 230Vac
Frequency: 50Hz
Resistive load continuous output power: 1500W
Capacitive load continuous output power: 490±50W, PF value: 0.584 (tri-color energy-saving lamps, exceeding may protect, but will not cause damage to the inverter)
Waveform: pure sine wave
Battery voltage: 12Vdc
Voltage range: 9.5V～15.5Vdc
DC current: 132.6A (1400W resistive load, input 12Vdc)
No-load loss: ≤1.4A (input 12Vdc)
Shutdown mode quiescent current: ≤1mA
Fan work: temperature and power control mode
Maximum efficiency: 91%
Battery input protection:
Fuse: 45A*4
Low battery alarm: 10Vdc buzzer alarm: Beep @ 0.5 Hz, LCD display code 06
Low Battery Alarm Recovery 11Vdc
Battery low voltage protection: 9.5Vdc to turn off inverter output, buzzer alarm: Beep @ 1 Hz, LCD screen displays code 01, 30S does not recover and automatically shuts down
Battery low voltage protection recovery: 12Vdc
Battery high voltage protection: 15.5Vdc turns off the inverter output, buzzer alarm: Beep @ 1 Hz, LCD screen displays code 02, 30S does not recover and automatically shuts down
Battery high voltage protection recovery: 15Vdc
Output protection:
High temperature protection: turn off inverter output, buzzer alarm: Beep @ 0.5 Hz, LCD display code 04
High temperature protection recovery: The inverter output is automatically restored when the temperature drops
Output short circuit: With short circuit protection, the inverter output will be turned off when the output is short circuited, the buzzer will alarm: Beep @ 1 Hz, the LCD screen will display the code 03, it will automatically shut down after 30 seconds, remove the short circuit and restart the machine to restore the output
overload
1. ENHANCE mode: the load exceeds 1500±100W and enters the constant current mode, continue to increase the power until the output voltage is lower than 160Vac, then turn off the inverter output in 10S, automatically shut down in 30S, turn off the load and restart to restore the output
2. Normal mode: the load exceeds 1500±100W and enters the constant current mode, continue to increase the power until the output voltage is lower than 175Vac, then turn off the inverter output in 10S, automatically shut down in 30S, turn off the load and restart to restore the output
3. Buzzer alarm: Beep @ 1 Hz, LCD screen display code 05
USB
Output voltage: 5Vdc
Output current: 2.1A
Working temperature: 0～40℃
Working humidity: 10～90%RH
Storage temperature and humidity: -20℃～60℃, 10～95%RH
Net weight: 2.33Kg
Size: 310*158*90mm(L*W*H)
Fuse: 45A*4
Low battery alarm: 10Vdc buzzer alarm: Beep @ 0.5 Hz, LCD display code 06
Low Battery Alarm Recovery 11Vdc
Battery low voltage protection: 9.5Vdc to turn off inverter output, buzzer alarm: Beep @ 1 Hz, LCD screen displays code 01, 30S does not recover and automatically shuts down
Battery low voltage protection recovery: 12Vdc
Battery high voltage protection: 15.5Vdc turns off the inverter output, buzzer alarm: Beep @ 1 Hz, LCD screen displays code 02, 30S does not recover and automatically shuts down
Battery high voltage protection recovery: 15Vdc
Output protection:
High temperature protection: turn off inverter output, buzzer alarm: Beep @ 0.5 Hz, LCD display code 04
High temperature protection recovery: The inverter output is automatically restored when the temperature drops
Output short circuit: With short circuit protection, the inverter output will be turned off when the output is short circuited, the buzzer will alarm: Beep @ 1 Hz, the LCD screen will display the code 03, it will automatically shut down after 30 seconds, remove the short circuit and restart the machine to restore the output
overload
1. ENHANCE mode: the load exceeds 1500±100W and enters the constant current mode, continue to increase the power until the output voltage is lower than 160Vac, then turn off the inverter output in 10S, automatically shut down in 30S, turn off the load and restart to restore the output
2. Normal mode: the load exceeds 1500±100W and enters the constant current mode, continue to increase the power until the output voltage is lower than 175Vac, then turn off the inverter output in 10S, automatically shut down in 30S, turn off the load and restart to restore the output
3. Buzzer alarm: Beep @ 1 Hz, LCD screen display code 05
USB
Output voltage: 5Vdc
Output current: 2.1A
Working temperature: 0～40℃
Working humidity: 10～90%RH
Storage temperature and humidity: -20℃～60℃, 10～95%RH
Net weight: 2.33Kg
Size: 310*158*90mm(L*W*H)
Features:
1. Pure sine wave
2. Peak power up to 3000W
3. Various types of protection: input high/low voltage protection, output short circuit protection, overload protection,
over temperature protection etc.
4. Applications: home appliances, power tools, office and portable equipment, vehicles and yachts, etc.
2. Peak power up to 3000W
3. Various types of protection: input high/low voltage protection, output short circuit protection, overload protection,
over temperature protection etc.
4. Applications: home appliances, power tools, office and portable equipment, vehicles and yachts, etc.
Package Includes:
1x Car inverter
