Specifications:
Brand |
Convoy |
Model |
S26A |
LED |
XHP70.3 HI R905，SFT40，XHP70.3 HI R70 |
Max Luminous flux |
4000LM XHP70.3 HI R70, 3000LM XHP70.3 HI R9050, 2000LM SFT40 |
Brightness Memory |
Yes |
Battery |
1 * 26800 or 26650 INR/IMR lithium battery (not included) |
Material |
6061 Aluminum Alloy |
Colour |
Black |
Waterproof rating |
IPX6 |
Switch Type |
Mechanical Switch at the End of the Flashlight. |
Driver Output Current |
6V 5A Boost for XHP70.3 HI , 3V8A BUCK for SFT40 |
Reflector Type |
Smooth Reflector for SFT40, Orange Peel Reflector for XHP70.3 HI |
Lens |
AR-Coated Glass |
Size |
33.1mm (Body Diameter), 150.2mm (Length) |
Net Weight |
180g (Without Packaging, Battery) |
Gross Weight |
196g |
Driver instructions:(12 groups)
1.click the switch to turn the flashlight on/off,tap the switch to select mode
2.if flashlight is turned on,tap the switch 20 times quickly to enter into config mode.(On a visual interface,as long as you click on an option, it means that the option is selected. The flashlight has no visual interface. It flashes to represent an option, and 'tap the switch in the flashing process' means to select the option.)
Option 1 (normal-flash 1 time + buzz-flash): tap the switch to enter into sub-option to select the mode group,If the user has no operation, the config mode will enter option 2.
-------------sub-option 1.1 (normal-flash 1 time) : tap the switch to select mode group 1 (0.1%, 1%, 10%, 35%, 100%, strobe, biking, battery-check)
-------------sub-option 1.2 (normal-flash 2 times) : tap the switch to select mode group 2 (0.1%, 1%, 10%, 35%, 100%)
-------------sub-option 1.3 (normal-flash 3 times) : tap the switch to select mode group 3 (100%, 35%, 10%, 1%, 0.1%)
-------------sub-option 1.4 (normal-flash 4 times) : tap the switch to select mode group 4 (1%, 20%, 100%, strobe, biking, battery-check, SOS)
-------------sub-option 1.5 (normal-flash 5 times) : tap the switch to select mode group 5 (1%, 20%, 100%)
-------------sub-option 1.6 (normal-flash 6 times) : tap the switch to select mode group 6 (100%, 20%, 1%)
-------------sub-option 1.7 (normal-flash 7 times) : tap the switch to select mode group 7 (0.1%, 1%, 10%, 50%, strobe, biking, battery-check, SOS)
-------------sub-option 1.8 (normal-flash 8 times) : tap the switch to select mode group 8(0.1%, 1%, 10%, 50%)
-------------sub-option 1.9 (normal-flash 9 times) : tap the switch to select mode group 9 (50%, 10%, 1%, 0.1%)
-------------sub-option 1.10 (normal-flash 10 times) : tap the switch to select mode group 10 (1%, 10%, 35%, 100%)
-------------sub-option 1.11 (normal-flash 11 times) : tap the switch to select mode group 11 (100%, 20%, strobe)
-------------sub-option 1.12 (normal-flash 12 times) : tap the switch to select mode group 12(100% only)
Option 2 (normal-flash 2 times + buzz-flash): tap the switch to active the mode memory or inactive it,If the user has no operation,flashlight will enter into the last mode.
Battery-Check Instructions:
<2.95v 1 Flash,
2.95-3.25v 2 Flashes,
3.25-3.55v 3 Flashes,
3.55-3.85v 4 Flashes,
>3.85v 5 Flashes
Package includes:
1 x Flashlight
1 x Rope
