Specification:

Input Voltage Range: DC 6V-12V (Input voltage must be at least 1V higher than the desired output voltage)
Output Voltages:
3.3V ± 0.2 error
5.0V ± 0.2 error
12V (Direct pass-through from input)
Output Current: 800mA (Load current should not exceed 800mA)
Input Adapter Voltage Range: 100-240V AC
Adapter Output: 12V 1A
Double Panel Design
PCB Board Size: 59.5mm x 26.5mm
DC Interface: 5.5mm x 2.1mm
Power Indicator: Red LED


Features:

1. High Stability: This DC-DC power supply module offers high stability and is designed for reliable performance.
2. Multiple Output Voltages: It provides three output voltage options - 3.3V, 5.0V, and 12V, making it versatile for various applications.
3. Wide Input Voltage Range: Supports input voltages ranging from 6V to 12V, accommodating different power sources.
4. Double Panel Design: The module features a double panel design that enhances durability and aesthetic appeal.
5. Easy Connectivity: Both input and output connections are facilitated through multiple pins, ensuring ease of use and secure connections.

Package Include:

1x DC-DC Power Supply Module
