Specifications:

>>>Manual: Click here to open<<<

Working voltage: 4.75-5.25V

SPIFlash: default 32Mbit

RAM internal: 520KB

Wi-Fi: 802.11b/g/n/e/i

Bluetooth: Bluetooth 4.2BR/EDR and BLE standard

Support interface: (2Mbps) UART, SPI, I2C, PWM

Support TF card, maximum support 4G

IO port: 9

Serial port rate: default 115200bps

Spectrum range: 2400 ~2483.5MHz

Antenna form: Onboard PCB antenna, gain 2dBi

Image output format: JPEG (only OV2640 support), BMP, GRAYSCALE

Packaging method: DIP-16

Transmit power 802.11b: 17±2dBm (@11Mbps)

802.11g: 14±2dBm (@54Mbps)

802.11n: 13±2dBm (@MCS7)

Receiving sensitivity CCK, 1Mbps: -90dBm

CCK, 11Mbps: -85dBm

6Mbps(1/2BPSK): -88dBm

54Mbps (3/464-QAM): -70dBm

MCS7 (65Mbps, 72.2Mbps): -67dBm

Power consumption Turn off the flash: 180mA@5V

Turn on the flash and adjust the brightness to the maximum: 310mA@5V

Deep-sleep: The lowest power consumption can reach 6mA@5V

Moderm-sleep: the lowest can reach 20mA@5V

Light-sleep: the lowest can reach 6.7mA@5V

Security: WPA/WPA2/WPA2-Enterprise/WPS

Working temperature: -20 ℃~ 70 ℃

Storage environment: -40 ℃~ 125 ℃, <90%RH

Features:

1. Use low-power dual-core 32-bit CPU, which can be used as an application processor.

2. The main frequency is up to 240MHz, and the computing power is up to 600 DMIPS.

3. Built-in 520 KB SRAM.

4. Support UART/SPI/I2C/PWM/ADC/DAC and other interfaces.

5. Support OV2640 and OV7670 cameras, built-in flash.

6. Support picture WiFI upload.

7. Support TF card.

8. Support multiple sleep modes.

9. Embedded Lwip and FreeRTOS.

10. Support STA/AP/STA+AP working mode.

11. Support Smart Config/AirKiss one-click network configuration.

12. Support secondary development.

Application:

Home smart device image transmission

Wireless monitoring

Smart agriculture

QR wireless recognition

Wireless positioning system signal

And other IoT applications

Package Include:

1× Development Board
