Specifications:
Model: HackRF One R9C
Operating Frequency: 1 MHz to 6 GHz
Transceiver Type: Half-duplex transmitter and receiver
Sampling Rate: Up to 20 million samples per second
Sampling Resolution: 8-bit quadrature sampling (8-bit I and 8-bit Q)
Compatibility: Works with software platforms such as GNU Radio and SDR#
Configurable Components: Software-adjustable gain control and baseband filtering
Antenna Port Power: Software-controlled (3.3 V at 50 mA)
Connector Type: SMA female antenna connector
Clock Sync Ports: SMA female clock input and output for synchronization
Interface: High-speed USB 2.0, Type-C connection
Power: USB-powered
Expansion Options: Internal pin header for additional development
Platform: Open-source hardware
Model: HAMGEEK MT1129 LNA
Charging Voltage: DC 5V
Battery: 4.2V, 350mAh
Antenna/Input Interface: SMA-K
Output Interface: SMA-JE
Charging Port: Type-C
Frequency Range: 100 kHz to 6 GHz
Noise Figure: < 0.8 dB NF
Gain: 20 - 35 dB
Impedance: 50 Ohms
Net Weight (with battery): 36 grams / 0.08 lbs
Features:
1.Wide Frequency Range (1 MHz–6 GHz): Easily capture, transmit, and analyze signals from a vast spectrum, supporting various radio frequencies via SDR technology for modern and future wireless communication exploration.
2.Open-Source Programmable SDR Platform: HackRF One’s open-source hardware design caters to flexible development and compatibility, supporting advanced SDR programs like GNU Radio and SDR#.
3.Enhanced Battery Management (H4): Enjoy battery status updates with an integrated screen showing charge percentage, voltage, and current flow, along with improved charging quality and automatic power-off when disconnected.
4.Low Noise Amplifier (LNA with NF < 0.8 dB): Reduce signal degradation with the HAMGEEK MT1129’s ultra-low noise levels and boost reception quality for SDRs, radios, and analyzers.
5.Outdoor-Friendly Screen Design: A built-in anti-glare display ensures clarity in bright sunlight, enabling effortless usage during field testing and analysis.
Package Included:
Type A:
1 x HackRF One R9C
5 x Antennas
1 x HAMGEEK MT1129 LNA
1 x Type-C USB Cable
Type B:
1 x HackRF One R9C
5 x Antennas
