Specification:
Working voltage: DC 4V--60V
Trigger signal source: high-level trigger (DC3.0V-24V), low-level trigger (DC 0.0V~0.6V), switching value control, can be connected to single-chip IO port, PLC interface, DC power supply, etc., can be connected to PWM signal , signal frequency 0−−2.5KHZ perfect support
Output capacity: DC4V-60V, continuous current 10A at room temperature, power 600W. Under the condition of auxiliary heat dissipation, the current can reach 15A
Application: The output terminal can control high-power equipment, motors, light bulbs, LED light strips, DC motors, micro pumps, solenoid valves, etc., and can input PWM to control the motor speed and the brightness of the lights, etc.
Service life: unlimited switch
Working temperature: -40~85℃
Size: 4.6*2.9*1.5CM
Features:
1. This module supports high-level trigger, low-level trigger, switching value control, PWM control system
2. Adopt imported dual MOS parallel active output, lower internal resistance, larger current, strong power, 10A, 600W at room temperature, which meets the needs of most equipment
3. Support ultra-wide voltage: DC 4V~60V
4. Easily realize the control of high-power equipment
Package Include:
1× Module Board
