Specifications:

Discharge Current: 100A

Charging Current (Same Port): ≤60A

Main Circuit Conduction Internal Resistance: ≤5mΩ

Discharge Overcurrent Protection: 150A±10A

Product Size: 146x62x8.36±1mm

Overcharge Protection

Detection Voltage: 3.65±0.025V

Detection Delay Time: 1000±500ms

Discharge Voltage: 3.5±0.05V

Over Discharge Protection

Detection Voltage: 2.35±0.1V

Detection Delay Time: 1000±500ms

Unwind Voltage: 2.7±0.1V

Equalization Parameters

Detection Voltage: 3.5±0.025V

Detection Delay Time: 50±50ms

Equalization Current: 30±5mA

Overcurrent Protection

Detection Voltage: 12.8±15mV

Detection Delay Time: 1000±500ms

Current Protection: 100±10A

Short Circuit Protection

Trigger Condition: External Short Circuit

Detection Delay Time: ≤300µs

Release Condition: Disconnect the Load

Temperature Control Protection

Charging High Temperature Protection Detection Temperature: 75°C

Discharge High Temperature Protection Detection Temperature: 75°C

Discharge Condition: 65°C

Self-Power Consumption
