Specifications:

Microcontroller Unit (MCU): ESP32-C6-MINI-1U

Dimensions: 32mm x 32mm x 34mm

Power Supply:

USB Charging Voltage: 5V

USB Charging Current: 500mA

Flash Memory: 4MB

Wireless Communication Protocols:

2.4GHz Wi-Fi 6

Bluetooth 5 (LE)

802.15.4

Board Features:

4 x LED (Control Pins: IO20, IO21, IO22, IO23)

Buzzer (IO14)

High-Efficiency Zero Standby Current Motor Driver:

Chipset: TMC6300

Type: Three-phase Motor

Maximum Current: 2A (Peak)

Hall Angle Position Encoder Sensor:

Sensor Chip: MT6701

0° to 360° Full Angle Detection

https://github.com/Xinyuan-LilyGO/T-Knob

Features:

1. Advanced ESP32-C6 MCU: Equipped with the ESP32-C6 microcontroller, this development board ensures powerful performance and superior connectivity. The MCU supports 2.4GHz Wi-Fi 6, delivering faster speeds and enhanced network efficiency. Meanwhile, Bluetooth 5 (LE) and 802.15.4 protocols provide versatile connectivity options, making it ideal for smart home, IoT applications, and more.

2. Integrated Position Encoder Sensor: The
