Specifications:

Frequency Range: 3.5MHz - 30MHz

Input Power: 1 - 5W (maximum 7W)

Output Power: 50W ±1.5dB at 13.8V

Output Impedance: 50Ω

Supply Voltage: 10V - 17.5V; 13.8V (typical value)

Current Consumption: ≤10A

Working Temperature: ≤55℃

Dimensions: 88 x 38 x 143mm (excluding protrusions), 88 x 38 x 160mm (including protrusions)

Weight: Approx. 0.65kg

Features:

1. Seamless Transmission/Reception Switching: High-speed RF-triggered switching eliminates the need for PTT SEND, ensuring smooth operation in both transmission and reception modes instantly.

2. Automatic LPF Band Adjustment: Integrated high-speed switching automatically adapts LPFs to the corresponding frequency band, covering 80m–10m HAM ranges, without requiring additional control cables.

3. Reliable Power and SWR Monitoring: Real-time power output and standing wave ratio monitoring safeguardthe amplifier's performance under various antenna conditions.

4. Comprehensive Voltage and Temperature Management: Wide voltage input support paired with temperature monitoring and protection ensures stable functionality even at outdoor lithium battery voltage levels or elevated temperatures.

5. Protocol Support for Major Brands: Compatible with ICOM, YAESU, and XIEGU band-switching protocols, allowing seamless integration with multiple radio systems (ACC cables required;
