Specifications:
Bandwidth: 25 MHz
Vertical Resolution: 8 bits
Channel Number: 2 (VDS2252/VDS2252I), 4(VDS2254/VDS2254I)
Sampling Rate: 100 MSa/s
Rise Time: ≤14 ns
Horizontal Scale: 5 ns/div – 1000 s/div, adjustable in steps of 1-2-5
Sampling Mode: Sample, peak detect, average
Record Length: 1 M
Input Coupling: DC, AC, Ground
Input Impedance: 1 MΩ ± 2%, parallel with 12 pF ± 5 pF
Max Input Voltage: VDS2252 & VDS2254: 40 V (DC + AC Peak); VDS2252I & VDS2254I: 400 V (DC + AC Peak)
Channel Isolation: 100:1 @ 50 Hz; 40:1 @ 10 MHz
DC Gain Accuracy: ±3%
Vertical Sensitivity: 2 mV/div – 10 V/div, adjustable in steps of 1-2-5
Trigger Type: Edge, Video, Slope, Pulse
Trigger Mode: Auto, Normal, Single
Line/Field Frequency: Supports NTSC, PAL, SECAM broadcast systems
Automatic Measurement: Vpp, Vmax, Vmin, Vtop, Vbase, Vamp, Vrms, Overshoot, Preshoot, Frequency, Period, Rise Time, Fall Time, Delay
Communication Interface: VDS2252 & VDS2254: USB Device (Type C); VDS2252I & VDS2254I: LAN (Isolation for I/I Models)
Power Source: DC 5V
Power Consumption: VDS2252 and VDS2252I: ≤ 5 W | VDS2254: ≤ 6 W | VDS2254I: ≤ 8 W
Device Dimensions: 190 x 18 x 120 mm (W x H x D)
Weight: Approx. 0.38 kg
Features:
a. Multi-Platform Compatibility
Compatible with Windows, For MacOS, For Linux, and Android systems through a tailored SDK, providing users with comprehensive access across operating environments for advanced testing and development.
b. High Precision Measurement
Offers 100 MSa/s sampling rate, 8-bit vertical resolution, and a rise time ≤14 ns, ensuring precise and accurate waveform analysis for critical testing scenarios.
c. Industrial-Grade Input Handling
Supports a maximum input voltage of up to 400 V (DC + AC Peak for I-versions), making it suitable for high-voltage applications with secure circuit isolation on selected models.
d. Versatile Trigger Options
Supports edge, video, slope, and pulse triggers and automatic measurement functions, simplifying test setups and enabling in-depth waveform diagnostics in varied operational contexts.
e. Compact Aluminum Alloy Design
The lightweight aluminum alloy chassis improves portability while ensuring efficient long-term operation in both research labs and field testing environments.
Package Included:
1 x Host
2 x Probes
1 x Quick Guide
