Features:- Compatible with lithium-ion and lead-acid battery, support user-defined batteries.- Automatic identification of 12V/24V/36V/48V system voltage.- A variety of protection functions to ensure the normal operation of the device and extend the battery life.- Natural air cooling heat dissipation, to achieve totally silent operation- The LCD screen enables real-time monitoring and parameter configuration.- Small size, light weight, easy and quick installation.- Built-in 2 USB ports with output of 5V and 2A.- User friendly setup, fast and easy commissioning via front panel LCD.Note: Do not charge Li-iron batteries if the battery temperature is below 0°C.
| Model | Pstar-30A | Pstar-60A | Pstar-80A |
| PV Input | |||
| Max Open Voltage of PV Module | 100V | ||
| PV Operation Voltage Range | >System voltage and ≤100V | ||
| Max. Input Power: | ≤360W | ≤720W | ≤960W |
| For 12V system | ≤720W | ≤1440W | ≤1920W |
| For 24V system | ≤1080W | ≤2160W | ≤2880W |
| For 36V system | ≤1440W | ≤2880W | ≤3840W |
| For 48V system | |||
| Charge Mode | |||
| Charging technology | PWM | ||
| Charge Algorithm | 3-Stages | ||
| Self-consumption | ≤20mA | ||
| Nominal System Voltage | 12V/24V/36V/48V | ||
| Rated Charging Current | 30A | 60A | 80A |
| DC output | |||
| Rated Output Current | 20A | 35A | 50A |
| USB Interface | 5V/2A*2 | ||
| Environment | |||
| Operating Temperature Range | -20℃~+55℃ | ||
| Humidity Range | ≤90%，Non-condensing | ||
| General Specification | |||
| Protection Class | IP30 | ||
| Dimension | 187*94*49mm | 187*132*60mm | 187*132*60mm |
| Net weight | 0.49kg | 0.7kg | 0.725kg |
Package includes:
1 x PWM Pstar Controller
UPGRADED SOLAR CHARGE CONTROLLER:Auto detect 12V 24V 36V 48V system, Max PV input voltage 100 volts, Max. Input Power: 720W-2880W;Compatible with lithium-ion and lead-acid battery, support user-defined batteries, Built-in Dual USB output 5V/2.5A (max), charging for your mobile phone, tablet, PC.
3-STAGE PWM Technology:The controller is equipped with advanced smart PWM technology with high charging efficiency, through three stages charge modes(Bulk, boost, float), fast, efficientand safe battery charge, effectively extend the battery life; combination of solar light control and time control, freely adjust the load enable duration.
14 TYPE BATTERY COMPATIBILITY:Compatible with various 12v 24V 36V or 48v batteries, such as SEL, USE, FLD, GEL, LiFePO4 and ternary lithium battery; with clear and special icons for various Lithium batteries on the LCD screen, easy select battery type; support user-defined batteries and calibrate battery voltage.
EASY-READ BACKLIT DISPLAY:Built-in Backlight LCD Screen, real-time monitor and control charging: charging current, generated energy, temperature, battery voltage, and error codes, fast and easy to set and commiss parameter; No matter how users switch display screen, it will automatically return to default display screen after no button is pressed for 100 seconds.
