Specifications:
Model: XTW6009 DC-DC Adjustable Boost Module
Input Voltage Range: 3V~32V (Digital display operates at 4.5V~32V)
Optimal Operating Voltage Range: 5V~32V
Output Voltage Range: 5V~35V
Maximum Output Current: 4A
Switching Frequency: 400kHz
Conversion Efficiency: Up to 94% (Efficiency decreases with higher pressure difference)
Output Ripple: ≤50mV
Load Adjustment Rate: ±0.5%
Voltage Adjustment Rate: ±0.5%
Working Temperature: -40°C~+85°C
Module Type: Non-Isolated Boost Converter (BOOST)
Rectification Type: Asynchronous Rectification
No-load Current: 18mA @ 5V input/8V output
Dimensions: 60mm x 35mm x 13.5mm
Weight: 24 grams
Features:
1. Wide Input and Output Voltage Range:
Operates over a substantial input range of 3V~32V and outputs 5V~35V, making it suitable for diverse applications like DIY power supplies, battery charging systems, automotive electronics, and industrial equipment.
2. High Efficiency Performance:
Equipped with built-in 4A MOSFET switching transistors, the module achieves conversion efficiency of up to 94%, ensuring reduced energy loss.
3. Advanced Voltage Display with Self-Calibration:
Features a digital voltmeter with self-calibration, providing precise voltage readings of ±0.05V. Users can switch between input and output voltage measurement and store settings after power cycling.
4. Compact Design with High Switching Frequency:
Operating at a frequency of 400kHz, it allows for smaller, cost-effective capacitors to be used, resulting in reduced ripple and compact size for space-constrained projects.
5. Built-In Protection Mechanisms:
Includes integrated overheating and short-circuit protection to maintain reliable function in critical power surge scenarios or other potential hazards.
Package Included:
1 x XL6009 DC-DC Adjustable Boost Module with Digital Display
