Module parameters:
1. Supply voltage: typical +5V (typical current value 90mA)
2. Gain: typical value 18dB@0.9G
3. Input and output impedance: 50 ohms
4. Maximum output power: P1db 22dBm(@2GHz
5. Input signal: <+10dBm (input can be as low as -110dBm, output signal is already distorted when input is greater than +10dBm)
6. Bandwidth: 0.05-4GHZ (gain is different at different frequencies, please refer to S21 curve index for details)
7. Noise figure: 0.6dB@0.9GHz
Package included:
(optional)
1 x RF Amplifier
1 x with Shell Amplifier
