Specifications:
Material:
Plastic components
M2.5 steel screws (Zinc plated)
Contact materials: phosphor bronze (Ni plated) or stainless steel
Pin header: Copper (Tin plated)
Housing: PBT, UL94V-0
Electrical:
Rated voltage: 300V
Rated current: 15A
Contact resistance: 20mΩ
Insulation resistance: 5000MΩ/1000V
Withstanding Voltage: AC1500V/1Min
Wire range: 22-14AWG/2.5mm²
Mechanical:
Temperature range: -30°C to +120°C
Maximum soldering temperature: +250°C for 5 seconds
Torque: 0.5Nm (3.6lb.in)
Strip length: 4.5-5mm
Features:
1. High Electrical Performance: Designed to handle a rated voltage of 300V and current up to 15A, this connector ensures robust and stable electrical performance for various applications, from industrial equipment to consumer electronics.
2. Superior Contact Materials: The use of phosphor bronze with nickel plating or stainless steel for contacts ensures excellent conductivity and resistance to corrosion. This enhances the longevity and reliability of the connections, providing peace of mind in critical applications.
3. Versatile Housing and Header Materials: The housing is made from PBT material, compliant with UL94V-0 safety standards, which
