Specifications:
Input Voltage: DC 8-35V
Input Current: 5.5A
Output Voltage: 5.2V
Output Current: Total Maximum 8A, Single USB Port up to 2A
Dynamic Response Speed: 300µs (load flow change 5%)
Conversion Efficiency: Up to 95% (12V to 5.2V 3.5A)
Load Regulation Rate: 0.2-0.3% (10%-50% load at 12V input)
Ripple & Noise: 120mVP-P (20MHz bandwidth 12V to 5.2V 3A)
Switching Frequency: 100KHz
No-load Current: 18mA (at 12V input)
Wiring Method: Terminal block DC seat
Fixed Mode: M31 M22
Net Weight: Approximately 36 grams
Physical Dimensions: 54 x 39 x 21 mm (including USB port)
Pin Mode: VIN+ (input positive), GND (common ground), OUT+ (output positive)
Features:
1. Advanced Charging Management: Equipped with 4 independent dedicated charging management IC, this module supports a variety of mobile phones for maximum current charging. It ensures fast charging, safety, and reliability, making it ideal for high-demand scenarios.
2. Wide Compatibility: The charging identification IC is compatible with the entire range of Apple and Android products, allowing most mobile phones to achieve the fastest charging speed. It offers
