Specifications:
- Operating Frequency: 300-330MHz
- Maximum Output Power (P1dB): 8W (39dBm) @8V 1.56A Efficiency 65%
- Input Power: 20~23dBm (0.1~0.2W), works below 0.1W with increased output as input power increases
- Operating Voltage: 6-8.4V (typical lithium battery supply voltage)
- Operating Current: 1.6A (Max)
- Input Impedance: 50 Ohms
- Output Impedance: 50 Ohms
- Connectors: SMA-k female (external thread, inner hole)
- Dimensions: 4x5.5cm (excluding protruding parts)
- Weight: 58g
- Performance: 8V supply, output 39.2dBm (8.3W), efficiency 66.6%
Features:
1. High Output Power:
Delivers up to 8W (39dBm) output, ensuring strong and reliable signal transmission within the 300-330MHz frequency range.
2. Energy Efficient:
Achieves an impressive efficiency of up to 66.6% at 8V supply, optimizing power consumption for longer battery life.
3. Compact and Lightweight:
With dimensions of 4x5.5cm and weighing only 58g, this module is ideal for space-constrained applications without adding significant weight.
4. SMA-k Connectors:
Equipped with standard SMA-k female connectors, allowing for easy integration with existing UHF communications setups.
5. Stable Performance:
Requires a properly matched 50 Oh
