Specifications:
| MCU | ESP32-S3R8 dual-core LX7 low-power SoC microprocessor |
| Wireless communication protocol | 2.4 GHZ Wi-Fi & Bluetooth5 (LE) |
| Development environment | for Arduino, PlatformlO-IDE, Micropython |
| Flash | 16MB |
| PSRAM | 8MB |
| WiFi antenna | ceramic antenna (default) |
| Onboard function | Boot + Reset + Power button |
| LED indicator light | red, blue and green |
| FPGA Chip | GW1NSR-LV4CQN48PC6/15 |
| Device GW1 NSR-4C | undefined |
| Package | QFN48P |
| Speed | C6/15 |
| LUT4 | 4608 |
| Flash | 256K |
| PSRAM | 64M |
| HyperRAM | 64M |
| NOR FLASH | 32M |
| Hard core processor | Cortex-M3 |
| Development Platform | Gowin FPGA Designer |
| Debug port | JTAG |
Features:
1. Powerful MCU: The ESP32-S3R8 dual-core LX7 low-power SoC microprocessor is the heart of this development board, providing high-performance computing power and low power consumption for your projects.2. Wireless Connectivity: With 2.4 GHz Wi-Fi and Bluetooth5 (LE) wireless communication protocols, this development board allows you to connect and control your devices remotely, making it perfect for IoT projects.
3. Versatile Development Environment: This development board supports multiple development environments, including Arrduino, PlatformlO-IDE, and Micropython, giving you the flexibility to choose the tools that work best for your project.
4. Ample Memory: With 16MB of flash memory and 8MB of PSRAM, you have plenty of space to store your code and data, ensuring that your projects run smoothly and efficiently.
5. FPGA Chip: The GW1NSR-LV4CQN48PC6/15 FPGA chip provides additional processing power and flexibility, with 4608 LUT4, 256K flash, 64M PSRAM, 64M HyperRAM, and 32M NOR flash. The Cortex-M3 hard core processor and Gowin FPGA Designer development platform make it easy to program and debug your FPGA projects.
Package Include:
【T-FPGA】:
1× Module Board
【T-FPGA Shield】:
1× Module Board
2× 2*3Pin
1× 2*10Pin
4× 2*6 Cured Pin
1× Screw
【T-FPGA+T-FPGA Shield】:
1× Module Board
2× 2*3Pin
1× 2*10Pin
4× 2*6 Cured Pin
1× Screw
1× T-FPGA
