Specification:
Brand: LILYGO®
Model: T5-4.7-S3 Pro
MCU: ESP32-S3-WROOM-1
Flash Memory: 16MB
PSRAM: 8MB
Wireless Connectivity: 2.4 GHz Wi-Fi & BLE 5
Programming Environment: Arduinos-IDE, VS Code
Onboard Functions: Touch, RTC PCF8563, TF Card
Battery Management Chip: BQ25896, BQ27220
Low Power LoRa Transceiver: SX1262
Support Baud: 433MHz, 868MHz, 915MHz (optional)
E-paper Display:
Driver IC: ED047TC1
Size: 4.7 inch
Gray Levels: 16
Resolution: 540 x 960
Features:
1. Advanced MCU: Equipped with ESP32-S3-WROOM-1, providing robust performance and wireless connectivity.
2. High-Resolution E-paper Display: The 4.7-inch ultra-low-power e-paper screen with 540x960 resolution offers clear and smooth visuals, supporting 16 gray levels.
3. Versatile Programming: Compatible with both Arduinos-IDE and VS Code, catering to different developer preferences.
4. Integrated LoRa Transceiver: The SX1262 module supports multiple baud rates, making it suitable for long-range, low-power applications.
5. Comprehensive Onboard Functions: Includes touch capabilities, RTC PCF8563, TF card slot, and efficient battery management with BQ25896 and BQ27220 chips.
Package Includes:
1 x LILYGO® T5-4.7-S3 Pro Epaper Pro Development Board(868MHz with GPS / 915MHz with GPS / 868MHz without GPS Optional)
2 x Screws
