Specifications:
Frequency Range: 1300MHz - 10GHz
VSWR: Less than 1.5
Impedance: 50 Ohms
Gain: 6±1dBi
Maximum Power Handling: 50W
Dimensions: 130 x 90 x 1.6mm
Connector Type: Available in both Female and Male connectors.
Features:
1. Versatile Application: Ideal for Beidou, GPS, 2.4GHz, 5.8GHz, and other communication systems, as well as for microwave anechoic chamber testing.
2. High-Performance Gain: Provides a directional gain of 6-9dBi across a wide frequency range, making it perfect for various tests like direction finding, spectrum analysis, and signal analysis.
3. Exceptional Bandwidth: Covers an extensive range from 1300MHz to 10GHz, ensuring high-fidelity signal reception and transmission.
4. Superb VSWR: Maintains a low VSWR (less than 1.5) for consistent and reliable performance, meeting EMC testing needs for continuous high field strength.
5. Robust Build: Constructed for exceptional longevity and reliability, designed to withstand rigorous testing environments.
Package Includes:
1x HT5 Antenna
1x SSMA-JJ Straight Male-to-Male Adapter
