Specifications:
Note: Please note that this product only has a step-down function and cannot boost the voltage.
| Scope of application | High-power LED constant current drive, lithium battery charging (including ferroelectric), 4V, 6V, 12V, 14V, 24V battery charging, NiCdNiMH battery (battery pack) charging , solar panels, wind generators |
| Input voltage | DC6-40V |
| Output voltage | Continuously adjustable (1.2-32VDC) below 32V for a long time (suitable for applications where the input voltage is higher than the output voltage and cannot be boosted) |
| Output current | Maximum 20A within 15A for a long time (power tube temperature exceeds 65 degrees, please add a fan to dissipate heat, high voltage output please derate use) |
| Adjustable resistance | 100K |
| Current limit range | 0.2-20A (adjustment) module exceeds 65 degrees, please add a fan . |
| Minimum dropout voltage | 3V |
| Operating frequency | 150KHZ |
| Conversion efficiency | Up to about 96% efficiency is related to dropout voltage and operating environment |
| Output ripple | Ripple around 50mV (excluding noise) 20M bandwidth (for reference only) input 24V Measured |
| Working temperature | -10°C to +75°C) (please pay attention to the power tube temperature in actual use, if the temperature is too high, please strengthen heat dissipation or derate use) |
| Potentiometer adjustment direction | Clockwise (increase), counterclockwise (decrease ) |
| Output short-circuit protection | YES (instantaneous protection) constant current (currently set constant current value can not be short-circuited for a long time) |
| Wiring method | Terminal block |
| Module size | 60*53*30MM |
| Net weight | about 85 grams |
Features:
Package Include:
1× Adjustable Step-down Power Module
