Specifications:
>>>Manual: Click here to open<<<
- Display: 3.2-inch color resistive touch screen
- Frequency Range:
- Display Frequency Range: 35 — 6200 MHz
- Measurement Frequency Range: 35 — 6200 MHz
- Dynamic Range:
- 35-3000 MHz: 75 dB
- 3000-4500 MHz: 70 dB
- Maximum Span: 6165 MHz
- Bandwidth: 200 kHz (fixed)
- Scan Speed for Frequency Bands over 100 MHz: 700 MHz/sec
- 100 MHz Scan Time: <0.25 sec
- Noise Floor:
- Up to 3000 MHz: <-90 dBm
- 3000-4500 MHz: <-85 dBm
- 4500-6200 MHz: <-80 dBm
- Wave Impedance: 50 ohms
- SWR (Standing Wave Ratio): <1.5 within operational frequency range
- Internal Attenuator Range: 0-30 dB
- Attenuation Accuracy:
- Up to 10 dB: 2 dB
- 10 to 20 dB: 5 dB
- 20 to 30 dB: 8 dB
- Tracking Generator Output Power: -15 to -25 dBm
- Accuracy within Dynamic Range: 2.0 dB<
