Specifications:
Microcontroller Unit (MCU): ESP32-C6-MINI-1U
Dimensions: 32mm x 32mm x 34mm
Power Supply:
USB Charging Voltage: 5V
USB Charging Current: 500mA
Flash Memory: 4MB
Wireless Communication Protocols:
2.4GHz Wi-Fi 6
Bluetooth 5 (LE)
802.15.4
Board Features:
4 x LED (Control Pins: IO20, IO21, IO22, IO23)
Buzzer (IO14)
High-Efficiency Zero Standby Current Motor Driver:
Chipset: TMC6300
Type: Three-phase Motor
Maximum Current: 2A (Peak)
Hall Angle Position Encoder Sensor:
Sensor Chip: MT6701
0° to 360° Full Angle Detection
https://github.com/Xinyuan-LilyGO/T-Knob
Features:
1. Advanced ESP32-C6 MCU: Equipped with the ESP32-C6 microcontroller, this development board ensures powerful performance and superior connectivity. The MCU supports 2.4GHz Wi-Fi 6, delivering faster speeds and enhanced network efficiency. Meanwhile, Bluetooth 5 (LE) and 802.15.4 protocols provide versatile connectivity options, making it ideal for smart home, IoT applications, and more.
2. Integrated Position Encoder Sensor: The
